Price from $ 59,500 (+GST)

Features & Benefits

  • A standard unit will feature all the necessities such as: JOST landing legs, 3-way twist locks, ramps for upper deck, tie-down points, 8mm thick laser cut side coaming, road-train bracket, LED side markers, ABS/EBS equipped.
  • Double welded I-Beam chassis construction allows for a tough and rigid frame.
  • Fully forklift and machine rated floors are standard.

BODY CONSTRUCTION

Side Coaming: 8mm Thick Cold-Rolled sheet steel. Tensile Strength = 650mPa
Flooring: 5mm Chequer-Plate flooring, mild steel at 350mPa tensile. Under-Floor construction consists of heavy duty I-Beam cross-members, with 30 x 30 x 3mm under-floor runners for extra support.
Skid-Plate: 12mm Thick Skid-Plate, with two position bolt-on king pin boss-plates fitted as standard.
Road-Train Bracket: 20mm thick folded C-Channel. With extra support gussets. Constructed from 350mPa mild steel.
Rear Tail-Gate: Standard ADR construction: Industrial C-250 channel – with multiple supports welded. Standrad rear bumper bar installed (constructed from 100 x 100 x 6mm RHS)

GENERAL

Length: Overall Length 45 FT (13720mm)- including the ramps
Width: Exterior: 2500mm
Height: 20 inch axles: 1100mm, 19.5 inch axles: 995mm, 15 inch axles: 920mm
Capacity (ATM): 45 Tonnes
Capacity GTM): 25 Tonnes
Tare Weight: Without Bi-Fold Ramps: 9.8 Tonnes With Bi-Fold Ramps: 10.5 Tonnes

UNDERFRAME

Chassis Beams I-Beam Construction: 20mm thick Flange plates (350mPa), 6mm Webbing plate (450mPa) – Half the chassis webbing is double plated for heavy duty construction.
Landing Gear: JOST A400 Landing Gear (JOST E100 Also used).
King-Pin: JOST 50mm or 90mm available.
